82.7%Efficiency
- DEFRA Exempt Smoke control areas
- Ecodesign Cleaner-burn standard
- Cleanburn Efficient secondary burn
- Airwash Keeps the glass clear
- External Air Direct outside air supply
- 12mm Hearth Decorative hearth ready
- A+ Rated Energy efficiency
Fire FX · Wood Burning Stoves
Fire FX Echo 5 Wood Burning Stove
£895supplied
The Echo brings refined, minimalist styling to modern living spaces. Clean contemporary lines and a wide viewing window frame the flames, while up to 82.7% efficiency and DEFRA-exempt, Ecodesign performance keep the burn clean, even in smoke control areas.
- DEFRA exempt, so you can burn even in a smoke control area
- Up to 82.7% efficient for more heat from every log
- Supplied and fitted by a HETAS-registered installer
Fire FX manufacturer RRP. Carl confirms the supplied price; the full installation is quoted after the home survey.
- HETAS registered
- Free home survey
- No-obligation quote
Key features
- Ecodesign compliant
- Maximum efficiency 82.7%
- Energy efficiency class A+
- Nominal heat output 5kW, range 3.5 to 7.5kW
- Cast iron and steel construction
- Large window for maximum flame view
- Radiant heat
- Simple to use controls
- DEFRA exempt for smoke control zones
- Cleanburn and Airwash systems
- Lined with high quality vermiculite panels
- 12mm hearth compatible
- Integrated external air connection
- Flue outlet 5 inch, top or rear
- Maximum log length 330mm
- 5 year extended warranty
- Designed and engineered in Britain
Specification
Echo 5 Wood
- Width
- 469mm
- Height
- 515mm
- Depth
- 396mm
- Nominal output
- 5kW
- Output range
- 3.5 to 7.5kW
- Efficiency
- 82.7%
- Energy rating
- A+
- Flue diameter
- 125mm (5 inch)
- Flue location
- Top or rear
- Direct air
- Yes
- DEFRA exempt
- Yes
- Ecodesign
- Yes
- Airwash
- Yes
- Cleanburn
- Yes
- Construction
- Cast iron and steel
- Weight
- 81kg
- Finish
- Black
- Minimum hearth
- 12mm
- Maximum log length
- 330mm
- Warranty
- 5 years
What's included in the fit
Every Carl Finnell installation is carried out by a HETAS-registered fitter and agreed on your home survey. A typical fit includes:
- The stove, supplied and sized to your room
- Flue or chimney liner, lined chimney or twin-wall flue
- Hearth and chamber work, finished to suit the room
- Register plate and the right cowl or terminal
- Testing, commissioning and first burn
- HETAS certificate, notified to building control
